Workshop -Introduction

Workshop SOE started from 2010-2011 Academic year in a creative way. The workshop team with all trades contributed from beginning for Academics requirement of University of Pune and development work of DYPTC. This workshop Team technically supports all colleges of knowledge city. We develop students to train for manufacturing operation of all branches so that they are employable. The few products developed by this Team with Students are
- Drawing Table (Standard and Retrofit able).
- Practical Tables.
- Class rooms Platforms.
- Students Two Seater and Single Seater Benches (In color along with book Nets).
Future Plans :
Also Central Workshop at DYPSOE has plans in coming future to introduce new Technology with software supports. Few items tentatively planned during AY 2014-15
Area :
- Pipe Bending Setup.(Tube, Rods and Different Sections etc )
- Powder Coating Setup.( For Finished Products )
- Use of Pressing/ Manufacturing Operations for studentSs project/ideas to help to develop them.
Gear Lever Mounted Clutch
- Student Name:
- Mr. MAHESH N. WAGH
- Mr. SHAUNAK S. DESHPANDE
- Mr. VISHAL A. RAMTEKE
Specification:
Gear box:
Type: - 4-Speed Constant mesh.
Gearbox ratio:- 5:1
Material: - Aluminium alloy.
Manufacturer:- Maruti-Suzuki
Length of spike shaft ( L ) - 95 mm
Pneumatic cylinder:
Bore diameter:- 60 mm
Stroke length:- 50 mm
Manufacturer:- Neulogic
Pressure required to overcome Spring Force:- 2.5 Bar
Normally Closed (NC) FCV(3/2)valve
Air tube: Diameter – 6x8 (IDxOD) mm

Semi-automatic Differential Locking System
- Student Name:
- Mr. Virkar Amol Uttam
- Mr. Wavhal Tejas Bharat
- Mr. Thorat Tushar Balasaheb
- Mr. Bhalerao Manoj Goraksha
Specification:
Gear box:
Power: (1/15) hp= 50 watts Single Phase AC motor ,1000rpm Belt Type
= V-Belt, Helicord Material, Open Type Belt Drive
Diameter of axle shaft - 16mm
Length of axle shaft (L ) - 230 mm
Diameter of spike shaft ( d ) - 16 mm
Length of spike shaft ( L ) - 95 mm
DC geared Motor:
Actuating Type: Automobile wiper assembly
Volts: 12 / 24 V
Current : 1 to 1.5 amp
RPM : ( a ) at high speed : 75 to 76 rpm
( b ) at low speed : 50 rpm
